Technical Specifications:
Display |
Type |
TFT Active Matrix LCD Display with LED backlight |
Dimensions (inches) |
16.14 (H) X 12.22 (W) X 3.13 (D) |
Weight |
12 lbs |
Ingress Rating |
IP65 Front | IP54 Back |
Screen Size |
15 inch diagonal |
Resolution |
1024 x 768 | 4:3 Aspect Ratio |
Glass |
2.8mm optically bonded tempered glass |
Coating |
Anti-Reflective Coating
|
Brightness |
1340 cd/m2 |
Brightness Control |
Push Button control 0-100% logarithmic |
Contrast |
5000:1
|
Colors |
16.7M |
Min Viewing Angle |
+/-89o(H), +/-89o(V) |
Touchscreen |
5-wire resistive touch
|
OSD Menu |
Front bezel mounted OSD menu buttons that allow directly accessible brightness up/down |
Power |
Input Power |
VOLTAGE: 9-36VDC
CURRENT: 3.3 AMP MAXIMUM @ 9 VDC
POWER CONSUMPTION: 30 WATTS MAXIMUM
|
Operating Temperature |
-20oC to 60oC |
I/O Ports |
USB Touchscreen
VGA Connector
DVI Connector
|
Certifications (Panel Mount Application) |
Shock |
MIL-STD-901D |
Vibration |
MIL-STD-167-1A |
Electromagnetic Interference (EMI) |
MIL-STD-461G |
Environmental |
MIL-STD-810G |
