Quarter-Turn Actuators

Quarter-Turn Marine Electric Valve Actuators

For Butterfly & Ball Valves

Quarter-Turn Actuators rotate a valve stem through 90 degrees to operate valves such as ball, butterfly, or plug valves. They convert an input signal (electric, pneumatic, or hydraulic) into mechanical motion, enabling precise control over valve positions.

Compact & Space-Efficient
High Torque Output
Durability in Harsh Environments
Remote & Automated Control
Fail-Safe Operation

Quarter-Turn Actuators

QT-50-Quarter-Turn-Electric-Valve-Actuator-1

QT-50 Quarter-Turn Actuator

The most compact quarter-turn actuator. With an operating torque of 50 Nm, the QT-50 is ideal for use with butterful and ball valves from DN25 - DN80. IP68 protection rating and maritime type approval ensures robustness and durability.

QT-70 Quarter-Turn Actuator

Suitable for butterfly and ball valves requiring up to 70 Nm of operating torque. Designed for maintenance-free operation with a compact footprint, permanently lubricated transmissions, and reliable performance in harsh maritime environments.

QT-250 Quarter-Turn Actuator

Engineered to be maintenance free, completely enclosed, and permanently lubricated. Suitable for a wide range of small to medium sized butterfly and ball valves with an operating torque of 50-250 Nm, this unit offers a high level of precision on the control of valves.

QT-400 Quarter-Turn Actuator

Suitable for butterfly and ball valves with operating torque requirements up to 400 Nm. Designed to be maintenance-free with permanently lubricated transmissions, IP68-rated protection, and reliable performance in harsh maritime environments.

QT-800 Quarter-Turn Actuator

Suitable for medium sized butterfly and ball valves with an operating torque of 250-800 Nm. Offers a high level of precision on the control of valves. Designed to be maintenance free and completely enclosed with permanently lubricated transmissions.

QT-1000 Quarter-Turn Actuator

Suitable for butterfly and ball valves with high-torque operating requirements up to 1000 Nm. Designed to be maintenance-free with permanently lubricated transmissions, intelligent control, and reliable performance in harsh maritime and industrial environments.
